MODEL

Unit

MDY100D

Rated heating capacity

KW

36

Average heating input power

KW

9.2

Rated heating input current

A

18

Max outlet water temp

C

35

COP

4.2

Power

V/Hz

380V/50

Noise

Db(a)

60

Dimension

W*D*H

mm

1450¡Á760¡Á1060

Packing size

W*D*H

mm

1520*760*1190mm

Unit weight

KG

360

Refrigerant

R417A/R407C

Working air temp range

(-20C)¡ª45C

compressor

Type

Copeland

Air source heat exchanger

Type

Finned heat exchange

Fan Type

axial flow fan

Hot water side heat exchange

Type

Titanium heat exchanger

Water flow

L/H

15000L/h

Water pressure down

Kpa

54

Pipe size

DN

50
