Application

 Apply to liquid circulation and filtration of Spa and bath

 small size swimming pools, water treatment facility and

 decoration pool...etc.

Features

 Electric pump over-current components using high-strength

 engineering plastics, with high-quality wear-resistant

 mechanical seal;

- With self-priming,    .

- 71 frame, equipped with specialized plastic mounting bracket.

 Pump apply forlow noise standard  motor. Single-phase with

 thermal protector from TI,USA.

- Motoris with high temperature  bearings, long operating life

 with reliability and durability.

- Complete separation of water and the axis, safe and reliable.

- Optional pneumatic switch, to ensure ease of use, security.

- Insulation class F, Protection IPX5.

- The pump obtained the certification of CE, TUV.

Working conditions

- Medium temperature:5-50¡æ

- Environmental temperature: ~40¡æ

- Max.working pressure: 0.3MPa
